Park Audio™
T122-P
Two-way
loudspeaker
Application: PA systems for clubs, bars, restaurants, music bands, indoor and outdoor usage.
- Maximum Output SPL 127 dB
- Frequency Range 52 Hz — 18 kHz
- 12”, 500 W neodymium LF driver (LAVOCE Italiana), voice coil 3”
- 1”, 60 W HF driver (B&C Speakers) voice coil 1.7”
- Coverage 90°H x 40°V
- Acoustic design – bass reflex
- Bi-Amp mode with separate amplifier for each frequency band and FIR signal processing
- Built-in amplifier 700 W + 350 W RMS with DSP engine for FIR sound processing
- LСD display for information output and system setup
- USB port for system setting by personal computer
- Built-in noise generator for live sound setting
- System menu for change sound setting: levels, EQ, separate components delay and general system delay
- Intuitive navigation through the system menu by means of encoder
- Ability to save 10 user presets
- Cabinet material – birch plywood
- Cabinet coating – black water-polymer finish (other colours available)
- Protective grid – perforated steel with powder coating
- Additional moisture protection — transpanent foam (glued to the inner surface of the grid)
- 6 Mounting holes M10
- Flange for speaker stand
| MODEL | T122-P |
|---|---|
| Loudspeaker | |
| Configuration | Active two-way loudspeaker |
| Acoustic Design | Trapezoidal housing, bass reflex |
| LF Driver | 12"dia LAVOCE Italiana, voice coil 3" |
| HF Driver | 1"dia B&C Speakers, voice coil 1.7" |
| Power Handling (nominal / continuous): | |
| – HF | 500 / 1000 W |
| – LF | 60 / 120 W |
| Frequency Range | 52 Hz - 18 kHz |
| Coverage | 90°H x 40°V |
| Maximum Output SPL (full space) | 127 dB/1m* |
| Weight | 26.5 kg |
| Dimensions: | |
| – width | 375 mm |
| – height | 575 mm |
| – depth | 390 mm |
| Built-in 2-channel Amplifier with DSP Engine | |
| Power Rating (RMS) | 700+350 W, class D |
| Sensitivity | 775 mV |
| Input Impedance | 10 kOhms |
| Signal-to-Noise Ratio | 98 dB (unweighted) |
| Input / Line Output | XLR/XLR |
| Power Requirements | ~220 / 230 V, 50 / 60 Hz |
| DSP engine | |
| Sampling rate | 48 kHz |
| DAC / ADC | 24-bit |
| Internal Processing | 56-bit |
* For comparison purposes and in accordance with common industry practice, maximum SPL specifications are calculations based upon transducer sensitivity, amplifier output voltage and speaker impedance.
** With smoothly variable intensity. At a normal temperature and low output level the fan is OFF.
